Overview[edit | edit source]

Template:Abstract

Description[edit | edit source]

Shared memory is supported by Qt through the QSharedMemory class. Two processes can share the same memory segment for IPC.

Solution[edit | edit source]

The SharedMemoryLoad application loads a string into the shared memory and the ShowSharedMem application shows the string from the shared memory.

  1. Run the SharedMemoryLoad application and click the Load button.
  2. Write some text in the input dialog.
  3. Send this application to the background.
  4. Run the ShowSharedMem application and click the Show from shared memory button. The text entered in the first application is displayed.

SharedMemoryLoad[edit | edit source]

SharedMemoryLoad is a class derived from QWidget. It contains the QSharedMemory object as a member variable:

  class SharedMemoryLoad : public QWidget
  {
      Q_OBJECT
      ...
  private:

      QSharedMemory sharedMem;
  };

In the SharedMemoryLoad class constructor, set the key for the shared memory object to "MySharedMemory":

  SharedMemoryLoad::SharedMemoryLoad( QWidget *parent )
  : QWidget( parent ),
    sharedMem( "MySharedMemory" ) {
    ...
  }

Loading a string into the shared memory:

  void SharedMemoryLoad::loadIntoSharedMem()
  {
    // First, test whether a shared memory segment is already attached to the process.
    // If so, detach it
    if (sharedMem.isAttached())
    {
      sharedMem.detach();
    }

    ...

    QBuffer buffer;
    buffer.open( QBuffer::ReadWrite );
    QDataStream out( &buffer );
    out << text;
    int size = buffer.size();

    if ( !sharedMem.create( size ) )
    {
      ui.LoadButton->setText(tr("Unable to create shared memory segment."));
      return;
    }

    // Write into the shared memory
    sharedMem.lock();
    char *to = (char*)sharedMem.data();
    const char *from = buffer.data().data();
    memcpy( to, from, qMin( sharedMem.size(), size ) );
    sharedMem.unlock();
  }

ShowSharedMem[edit | edit source]

In the same way as SharedMemoryLoad, ShowSharedMem is derived from QWidget and owns a QSharedMemory object.

  ShowSharedMem::ShowSharedMem(QWidget *parent)
  : QWidget(parent),
    sharedMem("MySharedMemory") {
    ...
  }


Loading from the shared memory:

  void ShowSharedMem::loadFromSharedMem()
    {
    if (!sharedMem.attach())
      {
      //If an attempt of reading from the shared memory before data is written
      ui.showButton->setText(tr("Enter a text first"));
      return;
      }

    QBuffer buffer;
    QDataStream in(&buffer);
    QString text;

    sharedMem.lock();
    buffer.setData((char*)sharedMem.constData(), sharedMem.size());
    buffer.open(QBuffer::ReadOnly);
    in >> text;
    sharedMem.unlock();

    // As this is the last process attached to the shared memory segment
    // the shared memory segment is released, destroying its contents
    sharedMem.detach();
    }

Sample application[edit | edit source]

File:QSharedMemoryExample.zip

Note: This example cannot be tested in the emulator because running multiple Qt applications in the emulator is not possible. Starting the second application returns KErrNotSupported(-5).
